Κατασκευαστής: Trf
Διαθεσιμότητα: Παραλαβή 1 εως 3 ημέρες
€200,00

TRF LSW158D1

TRF  LSW158D1

Size: 15inch

Cone: Competition  Grade Paper

Surround material: Foam

Voice coil: 3.0inch

RMS Power: 800Watt

Sensitivity: 89.2dB

Resonance frequency(f0): 33.1Hz

Magnet Weight: 110Oz

Υπολογισμός δόσεων

Ποσότητα

Στα Αγαπημένα
Credit module TBI Bank RO 1.0.11
adescription

SPECIFICATION:
MODEL: TRF LSW158D1

Size: 15

Cone: Competition  Grade Paper

Surround material: Foam

Voice coil: 3.0inch

Voice coil layer: 4layer

Nominal impedance: dual 1ohm

Voice coil wire: Coper

RMS Power: 800wrms

MAX Watt:1600wmax

Sensitivity: 89.2dB

Resonance frequency(f0): 33.1Hz

Mechanical Q factor(Qms): 5.98

Electrical Q factor:(Qes):0.63

Total Q factor:(Qts): 0.57

Xmax: 15mm

Force factor: 15.8N/A

Magnet Weight: 110 Oz



1=Outer Dimension:  393mm - 15.47"

2=Mounting Depth: 185mm - 7.28"

3=Magnet Dimension: 176mm - 6.90"

4=Mounting Hole Dimension: 350mm - 13.78"
