Κατασκευαστής: Trf
Διαθεσιμότητα: Παραλαβή 1 εως 3 ημέρες
€400,00

TRF SW1520M D1



  • Size: 15nch
  • RMS Power: 2000wrms
  • MAX Watt: 4000wmax
  • Cone: Paper many layers
  • Dust cap : Plastic
  • Surround material: Foam BIG
  • Voice coil bobbin: Aluminium
  • Voice coil dimension : 3.0inch
  • Voice coil layer: 8layer




Υπολογισμός δόσεων

Ποσότητα

Στα Αγαπημένα
Credit module TBI Bank RO 1.0.11
adescription

TRF SW1520M D1


  • Size: 15nch
  • RMS Power: 2000wrms
  • MAX Watt: 4000wmax
  • Cone: Paper many layers
  • Dust cap : Plastic
  • Surround material: Foam BIG
  • Voice coil bobbin: Aluminium
  • Voice coil dimension : 3.0inch
  • Voice coil layer: 8layer
  • Nominal impedance:D1
  • Voice coil wire: Copper
  • Spider dimension : 3''ID / 10''OD
  • Spider material : NOMEX
  • Spider layers :2pcs x 2layers
  • Basket:TRF Die cast Aluminium
  • Basket color:Red
  • Sensitivity: 94 dB
  • Frequency range:27-100Hz
  • Fs: 27 Hz
  • Mechanical Q factor(Qms):3
  • Electrical Q factor(Qes):0.6
  • Total Q factor:(Qts):0.5
  • Xmax: 28mm
  • Force factor: 19.4N/A
  • Magnet Weight: -300Oz
  • Basket:Die cast Alumium
  • Magnet:Ferrite ''high performance magnet''
  • Magnet dimension:Φ200*25 mm 3PCS
  • 1=Outer Dimension: 390mm
  • 2=Mounting Depth: 265mm
  • 3=Magnet Dimension: 200mm
  • 4=Mounting Hole Dimension: 355mm

  • Total weight :22kg
