KORG GRANDSTAGE X STAGE PIANO 88 KEYS

Stage piano νέας γενιάς με 88 βαρυκεντρισμένα πλήκτρα RH3 και λάμπα τεχνολογίας NuTube για πιο ζεστό ήχο.

____________________________________________________________________________________________________________

keyboard

• RH3 (Real Weighted Hammer Action 3) keyboard, A0 - C8, velocity supported, aftertouch not supported

Tone Generator

Method of Synthesis and Maximum Polyphony*

• SGX-2 (Acoustic Piano Sound Engine)
• EP-1 (Electric Piano Sound Engine)
• AL-1 (Analog Modeling Sound Engine)
• CX-3 (Tonewheel Organ Sound Engine)
• VOX Organ (Transistor Organ Sound Engine)
• FC-1 (Transistor Organ Sound Engine)
• HD-1 (PCM Sound Engine)
• Maximum Polyphony: 128

*The actual polyphony will vary depending on the synthesis engines and effects being used.

*KORG’s proprietary system dynamically allocates voice processing power between synth engines as necessary. The quoted maximum numbers of voices apply when 100% of the voice processing power is devoted to a single engine.Preload PCM Storage CapacityApprox. 25.5 GB (linear equivalent: approx. 51 GB)Number of Sounds700Favorite100 (including 20 preloads)

Effect

REVERB/DELAY

• Reverb types: HALL, STAGE, ROOM, SPRING, SHIMMER
• Delay type: DELAY, MOD DELAY, TAPE ECHOAUDIO INDyna Compressor、Exciter/Enhancer、Isolator、Multi-Mode Filter、Mastering Limiter、 Limiter、Graphic EQ、Modern Compressor

EQ

• 3-band equalizer: LOW, MID, HIGH

ANALOG TONE

• Vacuum tube analog sound effects with Nutube

Panel Interface

PART CONTROL section

• MAIN button, MAIN slider, LAYER button, LAYER slider, SPLIT button, SPLIT slider

UNISON Section

• UNISON button, UNISON slider

KEY TOUCH section

• KEY TOUCH button, KEY TOUCH slider

TRANSPOSE button, SWAP SPLIT button

.RHYTHM Section

• CHORD PROGRESSION button, KEY button, SETUP button, PLAY/STOP button, BASS MUTE button, TEMPO button

SOUND SELECT section

• 1[GRAND]~10[OTHERS] button, FAVORITE button

REVERB/DELAY section

• REVERB/DELAY button, TYPE button, DEPTH slider

EQ Section

• ON/OFF button, LOW, MID, HIGH sliderANALOG TONE sectionON/OFF button, DEPTH knob

Other

• Cursor UP/DOWN button, +/- button, function button, EXIT button, ENTER button, PANEL LOCK button, SYSTEM button, AUDIO IN button, power button

Controllers

Realtime Controller

• Pitch bend wheel, modulation wheel, SW1 button, SW2 button

Principal Specifications

Frequency Response

• 20Hz~20kHz: +/- 1.0dB, 10k ohm load

THD+N

• 20Hz~20kHz 0.005%,10k ohm load

S/N Ratio

• 105dB
• 10k ohm load

Audio Output

AUDIO OUTPUT XLR (LEFT, RIGHT)

• Connector: XLR-3-32 type (balanced) + LIFT-GND switch
• Output impedance: 600 ohm
• Maximum level: +16dBu
• Load impedance: 10kΩ

AUDIO OUTPUT(L/MONO、R)

• Phone connector: 6.3 mm TS phone jack (unbalanced)
• Output impedance: 1.1k ohm (stereo output), 600 ohm (L/Mono terminals, mono output)
• Maximum level: +16dBu
• Load impedance: 10k ohm

AUDIO IN

• Phone connector: 6.3 mm TRS phone jack (balanced)
• MIC/LINE switch
• LEVEL knob

Headphones

• Connector: 6.3 mm stereo phone jack
• Output impedance: 50 ohm
• Maximum level: 150mW+150mW @32 ohm

General

Control Input

• DAMPER (half damper supported), SWITCH, PEDAL

MIDI

• IN、OUT

Card Slot

• SDCard Slot

USB

• USB TYPE B x 1

Power Supply

• AC power supply terminal

Dimensions (W x D x H)

• 1,371 mm x 461 mm x 168 mm / 53.98” x 18.15” x 6.61” (excluding music stand)

Weight

• 25kg / 55.12 lbs. (excluding music stand)

Power Consumption

• 20W

Included Items

• AC cord, Music stand, Damper pedal (DS-1H)

Accessories (sold separately)

Expression/Volume

• XVP-20

Foot Controller

• EXP-2

Pedal Switch

• PS-3、PS-1

Hard Case

• HC-88KEY

Wooden Stand

• ST-WGS
