JBL COL600-BK HXOΣΤΗΛΗ 2WAY ME 2X5'' LF+ 1X1'' HF TWEETERS BK
JBL COL600-BK HXOΣΤΗΛΗ 2WAY ME 2X5'' LF+ 1X1'' HF TWEETERS BK
JBL COL600-BK HXOΣΤΗΛΗ 2WAY ME 2X5'' LF+ 1X1'' HF TWEETERS BK
JBL COL600-BK HXOΣΤΗΛΗ 2WAY ME 2X5'' LF+ 1X1'' HF TWEETERS BK
Κατασκευαστής: JBL
Διαθεσιμότητα: Παραλαβή 1 εως 3 ημέρες
€422,38

JBL COL600-BK
HXOΣΤΗΛΗ 2WAY ME 2X5'' LF+ 1X1'' HF TWEETERS BK


  • Ηχοστήλη
    2way με 2X5" LF+ 1X1" HF Tweters.
  • 70 Hz
    - 20     kHz.
  • Διασπορά: 110° κάθετη και 160 μοίρες για οριζόντια.
  • Διαθέτει βάση με ρυθμιζόμενη γωνία έως 10°.
  • SPL
    111    dΒ max.
  • Ισχύς: 20W,
    10    W, 5W @ 70V & 100V
    (επιπλέον 2.5    W @ 70V), και 8? (80W) μέσω επιλογέα.
  • IP54
    rating (IEC60529).
  • Διαστάσεις ΥΠΒ: (598 x 102 x
    93     mm).
  • Βάρος:
    3,5kg.
  • Xρώμα
    μαύρο.
















Υπολογισμός δόσεων

Ποσότητα

Στα Αγαπημένα
Credit module TBI Bank RO 1.0.11
adescription


General Specifications

Frequency Range (-10 dB)

  • 70 Hz – 20 kHz

Frequency Response (+/-3 dB)

  • 105 Hz – 20 kHz

Power Rating (8Ω setting)

  • 160W Continuous Program (2 hrs) ; 80W (320W peak) Continuous Pink Noise (2 hrs) ; 60W (240W peak) Continuous Pink Noise (100 hrs)

Sensitivity (2.83V @ 1m)

  • 86 dB

Coverage Pattern

  • Vertical 110° [1kHz-4 kHz average] ; 10° down-tilt to aiming access for +45°/-65° coverage in relation to physical cabinet aim ; Horizontal 160° [1kHz – 4 kHz average]

Directivity (Q)

  • 7.8

Directivity Index (DI)

  • 8.9 dB

Rated Maximum SPL

  • 105 dB Continuous (111 dB peak) @ 1m

Nominal Impedance

  • 8Ω (in Thru/direct mode)

Minimum Impedance

  • 7.0 Ω@ 275 Hz

Transformer Taps

  • 20W, 10W, 5W @ both 70V & 100V (plus 2.5W @ 70V), and 8Ω thru, selectable via switch

Transformer Insertion Loss

  • Less than 1 dB for all taps

Maximum Input Voltage

  • 21 V RMS (2 hrs), 42 V peak

Recommended Protective High-Pass

  • 70 Hz for 8 Ω operation; 60 Hz for all transformer tap settings (20W, 10W, 5W and 2.5W)

Drivers

  • Two 125 x 55 mm (5 x 2.25 in.) racetrack LF drivers ; One 25 mm (1 in.) tweeter (tweeter located at top of array for better coverage of listening space)

Dimensions

Dimensions (H x W x D)

  • 598 x 102 x 93 mm (23.6 x 4.1 x 3.7 inches)

Net Weight

  • 3.5 kg (7.8 lbs) each

Shipping Weight

  • 4.5 kg (10.0 lbs) each (packed 1 speaker per carton)

SPEC SHEET
