YAMAHA VXL1B-16P Ηχοστήλη 16x1.5

__________________________________________________________________________________________________________

General specifications

Speaker type

• Full-range, powered speaker, bass reflex

Frequency range (-10dB)

• 80Hz - 20kHz *1

Nominal coverage

H

• 170°

 V

• 25° (+12.5° - -12.5°)

Effective coverage (-10dB)

H

• 180°

V

• 30° (+15° - -15°)

Components

LF-HF

• 1.5"(3.75cm) Cone x 16

Maximum output level (1m; on axis)

102 dB SPL (when using PoE+(IEEE 802.3at)) *2

Power rating

Dynamic

• 15W (PoE+ (IEEE 802.3 at)), 6W (PoE (IEEE 802.3 af))

Continuous

• 15W (PoE+ (IEEE 802.3 at)), 6W (PoE (IEEE 802.3 af))

I/O connectors

• RJ-45 (Dante) x1

Protection circuit

Speaker processing

• Clip limiting, Integral power protection

Amplifier protection

• Over current protection, Over temperature protection, Under voltage lock out, DC detection, Clock detection

Power supply protection

• Over load protection, Over voltage protection, Under voltage lock out

Cooling

Natural convection

Power requirements

PoE+(IEEE 802.3at), PoE(IEEE 802.3af)

Power consumption

Idle: 3W, 1/8(Pink Noise): 6W (PoE+(IEEE 802.3at)), 4.3W (PoE(IEEE 802.3af))

Finish

VXL1B-16P: Black painting (approximate value: Munsell N3.0), VXL1W-16P: White painting (approximate value: Munsell N9.0)

Magnetic shielding

No

Dust and water resistant

No

Accessories

Mounting bracket x2, Bracket base x2, Safety wire x1, Machine screws (M5x10) x2, Template x1, Owner's manual

Options

WMB-L1B (W), HCB-L1B, PA-L1B

Packaging

Packaged in 1 pc

Dimensions (W x H x D)

W54 x H1120 x D104 mm (Speaker only)

Weight

• 5.0kg (Speaker only)

______________________________________________________________________________________________

*1: Half-space (2π)

*2: Measured peak SPL with IEC noise at 2m; value converted to 1m is shown (frequency range: 100 Hz - 10 kHz)
