ROKSAN Attessa Integrated Amplifier (Black)

_____________________________________________________________________________________________________________________________________________

Power Output into 8 Ohm

• 80W Both Channels Driven, Nominal (THD+N <0.1%)

Power Output into 4 Ohm

• 130W Both Channels Driven, Nominal (THD+N <0.1%)

Inputs (Digital)

• Digital 1 (D1) – Coax SPDIF (up to 192kHz/24bit)
• Digital 2 (D2) – Optical SPDIF (max. 96kHz/24bit)
• Digital 3 (TV) – Optical SPDIF (max. 96kHz/24bit)
• Digital 4 (CD) – Coax SPDIF (up to 192kHz/24bit)
• Digital 5 (Bluetooth) – Bluetooth (48kHz/16bit)

Inputs (Analogue)

• A1 – No signal sense
• A2 – With signal sense & used for AV Mode
• MM (Phono) – RIAA (equalised)

Outputs

• 1x pair Speaker binding posts (L&R)
• 1x pair of RCA Analogue (Pre-out/SUB)
• 3.5mm Stereo mini-jack headphone socket - 7.5Vrms drive suitable for all headphone types including high-impedance

Other

• IEC mains power socket (3 pin)/Fuse holder
• 3.5mm mini-Jack – 12v trigger Input (On / Standby)
• IR wired input 3.5mm jack

Construction

• Formed Plated steel and bespoke machined anodised aluminium front panel.

Primary Interface (on unit)

• Dynamic Control Dial (with haptic feedback) to control volume and inputs

Secondary Interface (on unit)

• Standby, Backward, Play/Pause, Forward

Other Interface

• IR remote

Bluetooth

• A2DP Audio profile / Codecs: SBC, aptX & AAC Bluetooth Range: 15m (typical)

Digital Coax Input

• up to 24bit/192kHz PCM

Digital Optical Input

• up to 24bit/96kHz PCM

MaestroUnite

• System Creation and Control

Advanced System Setting

• Over the Air Updates via Wi-Fi

Mains Transformer Rating

• 400VA

Dimensions (Including Encoder and Connections (W x H x D))

• 432 x 76 x 373 mm

Dimensions (Excluding Encoder and Connections (W x H x D))

• 432 x 76 x 346 mm

Weight

• 10.48 kg (23 lb)

Audio Formats

• MP3, AAC, WMA, OGG, WMA-L, ALAC, OPUS

Hi-Resolution Audio Formats

• MQA, FLAC, WAV, AIFF, Supports converted DSD playback via the BluOS desktop app (only)

Sampling Rate

• Up to 24 bit / 192kHz

Supported Operating Systems (Minimum Spec)

• Windows 7 SP1, macOS 10.9 Mavericks, iOS 9.3, Android 5.0 Lollipop or above

Supported Cloud Services

• Amazon Alexa, Amazon Music, Spotify Connect, TIDAL Connect, Deezer, Qobuz, HDTracks, HighResAudio, Murfie, JUKE, Napster, Slacker Radio, KKBox, Bugs

Free Internet Radio

• TuneIn Radio, iHeartRadio, Calm Radio, Radio Paradise

Control Integrations

• Crestron, Control4 (OS 3), Control4 (2.9.1), RTI, URC, Push, Lutron, ELAN, iPort

Format Support / Sampling Rate

• PCM / up to 192KHz/24bit
