FiiO JM21 Android 13 Hi-Res Music Player
FiiO JM21 Android 13 Hi-Res Music Player
FiiO JM21 Android 13 Hi-Res Music Player
Κατασκευαστής: Fiio
Διαθεσιμότητα: Άμεσα Διαθέσιμο
€216,00

FiiO JM21
Android 13 Hi-Res Music Player

New
octa-core 6nm Snapdragon 680 | Fully balanced audio design | 13mm ultra-thin
body | Dual CS43198+dual op-amps | Dual custom femtosecond crystal oscillators
| Android13 700mW+700mW output power | 4.7-inch HD display | 12.5h ultra-long
battery life Proprietary DAPS system without global SRC | 4.4mm+3.5mm outputs |
SPDIF/USB/LO audio outputs





Υπολογισμός δόσεων

Ποσότητα

Στα Αγαπημένα
Credit module TBI Bank RO 1.0.11
adescription


_______________________________________________________________________________________________________________________________________________

Specification

Size and Weight

Dimensions

  • 120.7mm x 68mm x 13mm

Weight

  • 156g



General

Name/Model

  • JM21

Hardware solution

  • Main controller: Qualcomm Snapdragon 680
  • DAC: CS43198 x2
  • Amp: SGM8262 x2

Working mode

  • Android mode/Pure music mode/USB DAC mode/Bluetooth receiving mode

Colour

  • Sky blue

Volume control

  • Physical button

Display

  • 4.7-inch (750x1334) bezel-less display

ROM/Usable storage

  • 32G ROM/22G ROM usable

RAM

  • 3GB

Adaptive impedance

  • PO: 8~150Ω
  • BAL: 8~350Ω

microSD card

  • Single microSD card expansion, theoretically supports up to 2TB

Channel balance

  • L20~R20 (0.5dB per level)

Buttons and Ports

Buttons

  • Power on/off x1
  • Volume button x2
  • Play/Pause x1
  • Previous track x1
  • Next track x1

USB

  • Type-C USB2.0*1 (Charging/Data transfer)

Headphone output

  • Standard 3.5mm port

Balanced headphone output

  • Standard 4.4mm port

Coaxial output

  • Standard 3.5mm port (shared PO)

Line output

  • Shared 3.5mm+4.4mm ports


Special Functions

WiFi

  • 2.4GHz/5GHz, Supports DLNA, AirPlay, WiFi song transfer, etc.

Bluetooth transmission (5.0)

  • AAC/SBC/aptX/aptX HD/LDAC/LHDC

Bluetooth reception (5.0)

  • SBC/AAC/LDAC

FIIO Link

  • Android supports WiFi and Bluetooth control; iOS supports Bluetooth control

Firmware upgrade

  • Supports upgrading through local storage + microSD card + OTA

Operation method

  • Supports gesture, two-button, and three-button operations

Power off timer

  • Supports idle/sleep power off

Max. supported sampling rate

  • USB DAC: Up to 384kHz/32bit; DSD256 (Native)
  • Local decoding: Up to 384kHz/32bit; DSD256 (Native)
  • USB Audio: 768kHz/32bit; DSD512 (DoP/D2P/Native supported)
  • Coaxial output: Up to 384kHz/24bit; DSD128 (D2P/DOP)


Power Supply

Power Supply

  • Supports 5V/≥2A

Charging Time

  • About 2h (5V, 2A charger)
