The tweeter, mid and bass drivers on the AE520 are constructed from carbon fibre, for a lightweight yet stiff cone, the ideal properties for a speaker driver. Carbon fibre is better damped than other hard dome tweeter materials, providing a lightning fast response combined with a natural sound. The aluminium WDT waveguide on the tweeter allows for optimum dispersion, and further reduces vibrations being passed on to the tweeter.

The AE520 speakers use two 125mm mid drivers, alongside three 125mm bass drivers, incorporating new oversized 35mm voice coils with very high motor force, to produce a dynamic yet highly controlled bass response. The mid woofers have an optimised motor and suspension system, ensuring mid-range definition and low distortion. The lightweight carbon fibre cone increases musical clarity, letting you hear your music with startling neutrality.

With a Mid Tweeter Mid (MTM) driver layout, with three lower bass drivers, the Acoustic Energy floorstanders utilise a 3-way crossover with high voltage polypropylene film capacitors creating optimum dispersion through a smaller acoustic source size. The AE520 cabinets are constructed of new Resonance Suppression Composite, evolved from Acoustic Energy’s Reference Series, with constrained layer composite to reduce unwanted vibrations which might colour the sound. Finished in high gloss black, white or walnut veneer, the clean lines of these speakers will suit any interior style.

Acoustic Energy AE520 Floorstanding Speakers features

• Carbon Fibre drivers for a lightweight yet stiff material
• Fast response and damped 25mm tweeter
• Aluminium WDT waveguide provides optimum dispersion of high frequencies
• Two 125mm carbon fibre mid drivers
• Three 125mm carbon fibre bass drivers
• 35mm oversized voice coils produce high dynamic range with controlled bass response
• Mid Tweeter Mid/bass driver layout with 3-way crossover
• Resonance Suppression Composite cabinets reduce vibrations and colour
•


• Brands

  Product Specifications

  Drive Unit 125mm carbon fibre cones Tweeter 25mm carbon fibre dome Frequency Range 30Hz – 28kHz (+/- 6dB) Sensitivity 90dB Peak SPL 113dB Power Handling 300w Crossover Frequency 373Hz / 2.8kHz Impedance 6ohms Design 3 way Grilles Slim, cloth magnetic fit Dimensions (mm) 1130 x 185 x 320 (HxWxD, exc. spikes) Weight 30kg (each) Finishes Piano Gloss White, Piano Gloss Black and American Walnut wood veneer
