TRF SPL SW2170NDGE D0.7
TRF SPL SW2170NDGE D0.7
TRF SPL SW2170NDGE D0.7
TRF SPL SW2170NDGE D0.7
TRF SPL SW2170NDGE D0.7
Κατασκευαστής: Trf
Διαθεσιμότητα: Παραλαβή 1 εως 3 ημέρες
€3.280,00

TRF SPL SW2170NDGE D0.7


MODEL: TRF
SPL SW2170NDGE D0.7

Size: 21nch

Cone:
Carbon FROM MADE IN EUROPE

Surround
material: Foam

Voice coil
made : MADE IN USA or MADE IN GREECE

Voice coil
dimension : 4.0inch

Voice coil
layer: 8layer

Dust cap :
Carbon FROM MADE IN EUROPE

Nominal
impedance: dual 0.7ohm

RMS Power:
7000wrms

RMS
Program: 18.000wrms

MAX Watt:
12.000wmax













































Sensitivity:
96dB

Υπολογισμός δόσεων

Ποσότητα

Στα Αγαπημένα
Credit module TBI Bank RO 1.0.11
adescription

SPECIFICATION:



MODEL:TRF SPL SW2170NDGE D0.7

  • Size: 21nch
  • Cone: Carbon FROM MADE IN EUROPE
  • Surround material: Foam
  • Voice coil made : MADE IN USA or MADE IN GREECE
  • Voice coil dimension : 4.0inch
  • Voice coil layer: 8layer
  • Dust cap : Carbon FROM MADE IN EUROPE
  • Nominal impedance: dual 0.7ohm
  • Voice coil wire: aluminium
  • Spider dimension : 4''ID / 10''OD
  • Spider material : NOMEX
  • Spider layers : 5pcs x 2layers
  • RMS Power: 7000wrms
  • RMS Program: 18.000wrms
  • MAX Watt: 12.000wmax
  • Sensitivity: 96dB
  • Vas: 250 L
  • Resonance frequency(fs): 33Hz
  • Frequency range: 33-100Hz
  • Mechanical Q factor(Qms):
  • Electrical Q factor(Qes):
  • Total Q factor:(Qts):
  • Xmax: 40mm
  • Force factor: N/A
  • Net weight: 46kg
  • Basket: Die cast Alumium
  • Magnet: NEODYMIUM
  • Magnet: NEODYMIUM ''high performance magnet''
  • Magnet dimension: Φ260*30mm X 1SET
  • 1=Outer Dimension: 550mm
  • 2=Mounting Depth: 330mm
  • 3=Magnet Dimension: 260mm

  • 4=Mounting Hole Dimension: 500mm
