TRF SPL SW2140NDGE D0.35
TRF SPL SW2140NDGE D0.35
TRF SPL SW2140NDGE D0.35
TRF SPL SW2140NDGE D0.35
TRF SPL SW2140NDGE D0.35
Κατασκευαστής: Trf
Διαθεσιμότητα: Παραλαβή 1 εως 3 ημέρες
€3.150,00

MODEL: TRF
SPL SW2140ND D0.35



  • Size:
    21inch
  • Cone:
    Carbon FROM MADE IN EUROPE
  • Surround
    material:     Foam
  • Voice coil
    made :     MADE IN USA or MADE IN GREECE
  • Voice coil
    dimension:     3.0inch
  • Voice coil
    layer:     8 layers
  • Dust cap:
    Carbon FROM MADE IN EUROPE
  • Nominal
    impedance:     dual 0.35ohm
  • RMS Power:
    4,000 wrms
  • RMS
    Program:     12,000 wrms
  • MAX Watt:
    8,000wmax


  •























    Sensitivity: 96dB

Υπολογισμός δόσεων

Ποσότητα

Στα Αγαπημένα
Credit module TBI Bank RO 1.0.11
adescription

SPECIFICATIONS:



MODEL: TRF SPL SW2140NDGE D0.35

  • Size: 21inch
  • Cone: Carbon FROM MADE IN EUROPE
  • Surround material: Foam
  • Voice coil made : MADE IN USA or MADE IN GREECE
  • Voice coil dimension: 3.0inch
  • Voice coil layer: 8 layers
  • Dust cap: Carbon FROM MADE IN EUROPE
  • Nominal impedance: dual 0.35ohm
  • Voice coil wire: aluminum
  • Spider dimension : 3''ID / 10''OD
  • Spider material: NOMEX
  • Spider layers: 5pcs x 2layers
  • RMS Power: 4,000 wrms
  • RMS Program: 12,000 wrms
  • MAX Watt: 8,000wmax
  • Sensitivity: 96dB
  • Vas: 250 L
  • Resonance frequency (fs): 31Hz
  • Frequency range: 31-100Hz
  • Mechanical Q factor (Qms):
  • Electrical Q factor(Qes):
  • Total Q factor: (Qts):
  • Xmax: 40mm
  • Force factor: N/A
  • Net weight: 46kg
  • Basket: Die cast Alumium
  • Magnet: NEODYMIUM
  • Magnet: NEODYMIUM ''high performance magnet''
  • Magnet dimension: Φ260*30mm X 1SET
  • 1=Outer Dimension: 550mm
  • 2=Mounting Depth: 330mm
  • 3=Magnet Dimension: 260mm
  • 4=Mounting Hole Dimension: 500mm
