TRF SPL SW1565CC D0.7
TRF SPL SW1565CC D0.7
TRF SPL SW1565CC D0.7
TRF SPL SW1565CC D0.7
Κατασκευαστής: Trf
Διαθεσιμότητα: Παραλαβή 1 εως 3 ημέρες
€1.320,00

TRF SPL SW1565CC D0.7

MODEL: TRF SPL SW1565CC D0.7

Size: 15nch

RMS Power: 6500wrms

RMS Program: 20.000 - 25.000wrms 3sec

MAX Watt: 13000wmax

Cone: Carbon FROM MADE IN EUROPE

Dust cap : Carbon FROM MADE IN EUROPE

Surround material: Foam

Voice coil bobbin: Aluminium

Voice coil made : MADE IN USA

Voice coil dimension : 4.0inch

Voice coil layer: 8layer

Nominal impedance: D0.7

Υπολογισμός δόσεων

Ποσότητα

Στα Αγαπημένα
Credit module TBI Bank RO 1.0.11
adescription

MODEL: TRF SPL SW1565CC D0,7

Size: 15nch

RMS Power: 6500wrms

RMS Program: 20.000 - 25.000wrms 3sec

MAX Watt: 13000wmax

Cone: Carbon FROM MADE IN EUROPE

Dust cap : Carbon FROM MADE IN EUROPE

Surround material: Foam

Voice coil bobbin: Aluminium

Voice coil made : MADE IN USA

Voice coil dimension : 4.0inch

Voice coil layer: 8layer

Nominal impedance: D0.7

Voice coil wire: aluminium

Spider dimension : 4''ID / 10''OD

Spider material : NOMEX

Spider layers : 4pcs x 2layers

Basket: Die cast Aluminium

Basket color: Red

Sensitivity: 93 dB

Frequency range: 35-100Hz

Fs: 35 Hz

Mechanical Q factor(Qms):

Electrical Q factor(Qes):

Total Q factor:(Qts):

Xmax: 30mm

Force factor: N/A

Magnet Weight: -Oz

Basket: Die cast Alumium

Magnet: Ferrite ''high performance magnet''

Magnet dimension: Φ280*25 mm 3PCS

GAUSS MOTOR:9000++


1=Outer Dimension: 385mm

2=Mounting Depth: 295mm

3=Magnet Dimension: 280mm

4=Mounting Hole Dimension: 354mm

Total weight : 48kg
